Specifications
| Net Rated Amperes | 100 Amperes |
| Rpm Rated Amperes | 4500 |
| Preset Voltage Range | 37.5 - 38.0 Volts DC |
| Full Load Voltage | 37 (with 37.5 V. DC Preset Voltage) |
| Full Load Field Coil Amps | 4.5 |
| Grounding Options | ISOL., NEG., POS., Internal |
| Rotation | Bidirectional |
| Shaft Pulley OD | 7/8" |
| Rpm Terminal | Standard |
| Voltage Regulator Std | Integral, Adjustable, Self-Exciting |
| Voltage Regulator Opt | Remote, Self or Ignition Excited |
| Wiring Std | 2-Wire |
| Wiring Opt | 1-Wire (Internal Ground) |
| Diode Construction | Individually Replaceable |
| Diode Capacity | 225 |
| Amps | 100 |
| Fan Location | External |
| Mount Hole 1 Type | Threaded |
| Mount Hole 2 Type | Unthreaded |
| Mount Hole 3 Type | Unthreaded |
| Mount Hole ID 1 | 1/2-13 |
| Mount Hole ID 3 (metric) | 13mm |
| Polarity | Insulated |
| Regulator Location | Internal |
| Terminal 2 Size | 5/16-18 |
| Terminal 3 Size | 10-32 |
| Terminal ID 2 | B+ |
| Terminal ID 3 | R |
| Volt | 24 |
